Warmtepompen voor woningen
No.1
Heating capacity 3000/8500
input power600-1750
Rated output water quantily (L)245
Maximum output water temperature ('C)60
net weight (kg) 75
Noise( <db(A)) 50
Rated voltage/frequency(V/Hz) 220V~/50Hz
Dimension(L*W.Hmm) 900x350x1250
No.2
Heating capacity 5000-12400
input power 1000-3200
Rated output water quantily (L) 345
Maximum output water temperature ('C) 60
net weight (kg) 110
Noise( <db(A)) 50
Rated voltage/frequency(V/Hz) 220V~/50Hz
Dimension(L*W.Hmm) 965x350x1380
No.3
power source 220V-50/60Hz
rated output temperature 55'C
heating capacity 10KW
rated input power 2.52KW
testcondition:DBtemperature 20'C,WB temperature 15'C,water output temperature 45 'C (heating condition)
heating capacity 8.45KW
rated input power 2.48KW
testcondition:DBtemperature 7'C,WB temperature 6'C,water output temperature 45 'C (heating condition)
cooling capacity 7.5KW
rated input power 2.56KW
Max input power 3.25KW
Max current 14.8A
Rated water flow 1.3m3/h
Noise <50db(A)
Unit size 110x330x965mm
Unit weight 90kg
No.4
power source 220V-50/60Hz
rated output temperature 55'C
heating capacity 20KW
rated input power 4.29KW
testcondition:DBtemperature 20'C,WB temperature 15'C,water output temperature 45 'C (heating condition)
heating capacity 14KW
rated input power 4.11KW
testcondition:DBtemperature 7'C,WB temperature 6'C,water output temperature 45 'C (heating condition)
cooling capacity 12.5KW
rated input power 4.3KW
Max input power 5.4KW
Max current 24.5A
Rated water flow 2.15m3/h
Noise <50db(A)
Unit size 110x330x1250mm
Unit weight 135kg
No.5(3 in 1)
power source 220V-50/60Hz
rated output temperature 55'C
heating capacity 22KW
rated input power 5.24KW
testcondition:DBtemperature 20'C,WB temperature 15'C,water output temperature 45 'C (heating condition)
heating capacity 16.8KW
rated input power 4.94KW
testcondition:DBtemperature 7'C,WB temperature 6'C,water output temperature 45 'C (heating condition)
cooling capacity 15KW
rated input power 5.26KW
Max input power 6.5KW
Max current 29.5A
Rated water flow 2.41m3/h
Noise <50db(A)
Unit size 110x330x1250mm
Unit weight 138kg
